How do you rotate a sketch in Freecad?

Usage

  1. Select the sketch to be revolved. v0. 17 and above A face on the existing solid can alternatively be used.
  2. Press the Revolution button.
  3. Set the Revolution parameters (see next section).
  4. Press OK.

How do you create a construction line in Freecad?

Usage

  1. Invoke construction mode by clicking on the Toggle construction or by using the Sketch → Sketcher geometries → Toggle construction geometry entry in the Sketcher menu.
  2. This will change the color for creating new geometric elements to blue.
  3. Newly created geometric elements will now be created in construction mode.

How do you do external geometry in Freecad?

Usage

  1. Create a new sketch, or open an existing sketch.
  2. Click ‘Sketcher External’ button.
  3. Select an edge or a vertex that you want to link to in the sketch.
  4. Press Esc, or select another tool to stop importing geometry into the sketch.

How do I make a sketch solid in Freecad?

FreeCAD: How to create solid from a sketch?

  1. Click [File]-[New] in menu bar and create new document .
  2. Move to Part Design workbench.
  3. Select “New Sketch”
  4. Select “Circle”
  5. Click the center of the circle and the center becomes selected state(green color).
  6. Coordinates of the center point are displayed on 3D View as numbers.

How do I get a body active on FreeCAD?

Double-click the Body in the tree view or open the context menu (right-click) and select Toggle active body to activate or deactivate the Body. If another Body is active, it will be deactivated.

How do I use the polarpattern feature?

Above: a slot-shaped pocket (B) made on top of a base solid (A, also referred to as support) is used for a polar pattern. The result (C) is shown on the right. (Optional) Select the feature ( introduced in version 0.19 or several features) to be patterned. Press the PolarPattern button.

How to change the axis of a polar pattern?

An axis being normal to the sketch and starting in the origin of the sketch of the feature being used is taken as axis for the polar pattern. The pattern direction can be reversed by ticking ‘Reverse direction’. Uses the horizontal axis of the sketch for axis. Uses the vertical axis of the sketch for axis.

Why does FreeCAD tell me that the transformation has failed?

But FreeCAD will not allow me to proceed. It tells me that the Transformation has failed! The reason that FreeCAD thinks the Transformation has failed is because one (or more) of the transformed shapes (lines) did not intersect the Plate.
